Stainless Steel Bar

201 Stainless Steel Bar

201 stainless steel is the steel that is resistant to the corrosion of weak media such as atmosphere, steam and water, while acid resistant steel refers to the steel that is resistant to the corrosion of chemical corrosive media such as acid, alkali and salt.

 WhatsApp:

 201 stainless steel bar is composed primarily of iron with between 16 and 18% chromium and less than 0.15% carbon. It also contains small amounts of manganese, nickel, silicon, nitrogen, and copper. In addition, it can be hardened by cold working processes but not heat-treated like 304 or 316 grades, since it has higher formability than the 300 series grades. 201 stainless steel bar has high manganese but low nickel content. So its corrosion resistance is not as superior as 300 series. 201 stainless steel bars are widely used as parts in manufacturing kitchenware, outdoor decoration engineering, urban decoration industry and low-grade household products. They are also used in medical instruments and automotive parts that require flexibility while maintaining strength under pressure.

Product Parameters

Product Name201 Stainless Steel Bar
TypeSteel Bar
Outer Diameter (Round Bar)4mm - 500mm
Outer Diameter (Hexagon Bar)18mm - 57mm (11/16″ to 2-3/4″)
Outer Diameter (Square Bar)18mm - 47mm (11/16″ to 1-3/4″)
Flat Steel1/2″ to 10″, Thickness: 2mm - 150mm (customizable)
Length1 - 6 meters (customizable)
StandardASTM, AISI, JIS, GB, DIN, EN, etc.
SurfaceBlack, Bright Polished, Rough Turning, Mattness Surface Treatment, No.4, BA, etc.
Scope of Application Shipbuilding, defense, automotive, textiles, paper and pulp, manufacturing, cement, heavy earthmoving equipment and construction, etc.

Chemical Composition

CSiMnCrNiSPMo
≤ 0.03 ≤ 1.0 ≤ 2.0 16.0 – 18.0 10.0 – 14.0 ≤ 0.03 ≤ 0.045 2.0 – 3.0

Mechanical Properties

Tensile Strength Kb (MPa) Yield Strength σ0.2 (MPa) Elongation D5 (%) Hardness
≥ 480 ≥ 177 ≥ 40 ≤187HB / ≤90HRB / ≤200HV

Physical Performance

Density (g/cm³) Modulus of Elasticity (GPa) Thermal Expansion (10⁻⁶/°C) Thermal Conductivity (W/m·K) Resistivity (μΩ·cm)
7.99 193 16.0 16.2 74
