Alloy Pipe
Titanium Grade 2 Pipe
Titanium Grade 2 pipe is known for its excellent corrosion and heat resistance. This alloy offers a high degree of durability and stability, making it ideal for use in a variety of environments. In addition, Titanium Grade 2 pipe is lightweight, high-strength and has good processability. These advantages make it an ideal substitute for traditional metal materials in many fields.
Grade 2 titanium is industrial pure titanium. The strength is not high, but the plasticity is good, It is easy to process and form. Grade 2 titanium has good corrosion resistance in the atmosphere, sea water, wet chlorine and oxidation, neutral, weak reducing medium. It has better oxidation resistance than most austenitic stainless steel, but weaker heat resistance. Titanium alloy usually operates in humid atmosphere and seawater media, it is particularly resistant to pitting corrosion, acid corrosion, and stress corrosion. Moreover, it is resistant to alkali, chloride, chlorine-based organic substances, nitric acid, and sulfuric acid. etc. However, titanium has poor corrosion resistance to media with reducing oxygen and chromium salts.
Product Parameters
| Product Name | Titanium Grade 2 Pipe |
|---|---|
| Outer Diameter |
Round Pipe: 4mm - 200mm Square Pipe: 10*10mm - 100*100mm Rectangular Pipe: 10*20mm - 50*100mm |
| Wall Thickness | 0.6mm - 6.0mm |
| Length | 1 - 6 meters (Length can be customized) |
| Standard | ASTM, AISI, JIS, GB, DIN, EN, etc. |
| Surface | Black, Bright Polished, Rough Turning, Matt Surface Treatment, No.4, BA, etc. |
| Certificate | ISO, SGS, BV |
| Production Technology | Hot Rolling, Cold Rolling |
Chemical Composition
| C | Al | Si | S | Ti | Cr | Mn | Fe | Ni | Cu |
|---|---|---|---|---|---|---|---|---|---|
| 0.1 max | 0.15 - 0.60 | 1.0 max | 0.015 max | 0.15 - 0.60 | 19.0 - 23.0 | 1.5 max | 39.5 min | 30.0 - 35.0 | 0.75 max |
Mechanical Properties
| Tensile Strength (ksi) | 0.2% Yield Strength (ksi) | Elongation % in 2 inches |
|---|---|---|
| 75 | 30 | 30 |
Physical Performance
| Item | Value | Temperature (°C) |
|---|---|---|
| Density | 7.94 g/cm³ | Room |
| Specific Heat | 0.11 Kcal/kg·C | 21° |
| Melting Range | 1357 - 1385°C | - |
| Modulus of Elasticity | 196.5 KN/mm² | 20° |
| Electrical Resistivity | 98.9 µΩ·cm | 20° |
| Coefficient of Expansion | 14.4 µm/m·°C | 20 - 100° |
| Thermal Conductivity | 11.5 W/m·K | 20° |
